Let’s write an AI Keeper for Call of Cthulhu! — Part II: Making tools

No, I still haven’t found a human to play CoC with me.

Previously in Part I: Design & Demo, we examined how a game of Call of Cthulhu (CoC) flows from start to finish, identified a few components that we need to build if we want to make an AI Keeper, and previewed what the final product may look like. We also picked a software stack, a large language model (LLM), and a function-calling paradigm after some brief catch-ups with the latest updates in this field of research.

Now comes the fun part. We need to build the tools that the AI Keeper can use.

The search engine integration

Let’s start with the easiest one, which is the search engine integration. As mentioned earlier, we can use Tavily for this purpose. LlamaIndex has a well-maintained integration package with Tavily. It’s available in its repository of agentic tools, not-so-creatively named LlamaHub. (I’m curious about who started it, calling everything “something-hub”. Was it GitHub? Hugging Face Hub? JupyterHub?) All we need to do is to install the package and use it in our code like this:

from llama_index.tools.tavily_research import TavilyToolSpec
if api_key := os.environ.get("TAVILY_API_KEY", None):
    tavily_tool = TavilyToolSpec(
        api_key=api_key,
    ).to_tool_list()
else:
    tavily_tool = []
# then...
    cl.user_session.set("agent",
      OpenAIAgent.from_tools( # ...
        tools=tavily_tool + [...],
    ))

Secret management. In the snippet above, we are reading the API key from the environment variable TAVILY_API_KEY. "Does it mean I have to supply that env var every time I run the script, or do I have to add it into my .profile script?", you may ask. No, you don't have to! Here's a lesser-known side effect of using Chainlit: It automatically reads the environment variables from a .env file in the project root, thanks to its usage of the python-dotenv package. The more you know.

A peek under the hood. In the first post of this series, I demonstrated that our AI Keeper could consult the internet when both of us were unsure about a particular rule. Behind the scene, this was what happened:

Incorporating an arbitrary PyPI library

What if our chosen library lacks an off-the-shelf integration with LlamaIndex? That’s where we have to specify the tool’s metadata ourselves. The nominal example in our project is Cochar, our character creation tool of choice.

Cochar even has a web UI.

At the minimum, Cochar only requires a year and a country to generate a full character profile:

>>> print(cochar.create_character(1995, "US"))
Character
Name: Breland Justice
Sex: M, Age: 38, Country: US
Occupation: Tribe member
STR: 85 CON: 18 SIZ: 90
DEX: 81 APP: 15 EDU: 57
INT: 90 POW: 45 Luck: 35
Damage bonus: +1K6
Build: 2
Dodge: 40
Move rate: 7
Skills:
| Climb: 86 || Throw: 78 || Natural world: 15 |
| Listen: 22 || Occult: 15 || Spot hidden: 20 |
| Fighting (sword): 75 || Survival (jungle): 88 || Archeology: 67 |
| History: 6 || Locksmith: 49 || Mechanical repair: 42 |
| Pilot: 12 || Fast talk: 17 || Persuade: 16 |
| Fighting (whip): 8 || Language (latin): 2 || Credit rating: 7 |

The output format needs an overhaul, though. For CLI programs, these ASCII tables are fine, but they will look horrible in a chat bubble. I want a natural-language description of generated characters, so the LLM will run over the raw output. However, LLMs are sensitive to table formats (choice of delimiters, etc.) and partition marks (where a table begins and ends), both of which are improvised quite liberally in the above design. Let’s avoid risking typography biasing our AI: We’d be better off standardizing to a data serialization format that your LLM likely have seen a lot, across numerous topics.

In terms of popularity, what can possibly be a better option than JSON?

>>> print(cochar.create_character(1995, "US").get_json_format())
{'year': 1995, 'country': 'US', 'first_name': 'Japheth', 'last_name': 'Rowles', 'age': 46, 'sex': 'M', 'occupation': 'chauffeur', 'strength': 28, 'condition': 68, 'size': 65, 'dexterity': 61, 'appearance': 23, 'education': 57, 'intelligence': 76, 'power': 31, 'move_rate': 6, 'luck': 26, 'damage_bonus': '0', 'build': 0, 'skills': {'drive auto': 38, 'mechanical repair': 75, 'navigate': 83, 'psychology': 79, 'persuade': 18, 'art/craft': 30, 'acting': 49, 'jump': 79, 'library use': 21, 'pilot': 18, 'psychoanalysis': 2, 'stealth': 22, 'track': 12, 'credit rating': 25}, 'dodge': 30, 'sanity_points': 31, 'magic_points': 6, 'hit_points': 13}

We can wrap this into a small function called make_character. To declare it as a tool for LlamaIndex Agents, just wrap it with FunctionTool.from_defaults:

@wraps(cochar.create_character)
def make_character(*args, **kwargs) -> dict:
    character: Character = cochar.create_character(*args, **kwargs)
    return character.get_json_format()

tool_for_creating_character = FunctionTool.from_defaults(
    make_character,
)

FunctionTool.from_defaults (and its LangChain equivalent, @tool) uses the docstring to describe the tool to the LLM, so we want to keep the docstring intact. (If it's not obvious -- cochar.create_character has a huge docstring, whereas make_character has none.) That's where @wraps comes to play. It copies a handful of attributes of the original function to the wrapper function, including the docstring.

We are not done yet. As part of the Character class, Cochar also brings in a special class, SkillsDict. This customized dictionary type has an overridden __setitem__ method, which Pydantic -- the library that LlamaIndex uses to infer input schema from function signatures -- doesn't like:

pydantic.errors.PydanticSchemaGenerationError: Unable to generate pydantic-core schema for <class ‘cochar.skill.SkillsDict’>. Set arbitrary_types_allowed=True in the model_config to ignore this error or implement __get_pydantic_core_schema__ on your type to fully support it.

“Wait, where did you see __setitem__ in the complaint?", I hear you ask. This brings us to a detour of some Python niches. Notice that SkillDict is declared as a subclass of the built-in type, UserDict.

class SkillsDict(UserDict):

If you monkey-patched this UserDict to dict, Pydantic would stop complaining. However, SkillsDict needs to override __setitem__, so it can't subclass dict and have to implement the Abstract Base Class (ABC) MutableMapping. The class UserDict serves as a default implementation for just that. To paraphrase this Stack Overflow answer:

• You subclass dict if you want to extend (i.e., add more methods to) dict, and
• you subclass UserDict if you want to override (i.e., rewrite existing methods on) dict.

That’s enough detour of Python niches; back to the problem at hand. arbitrary_types_allowed looks risky to me, and I don't have control over the SkillsDict class. Let's just write a tool schema by hand:

class CreateCharacterRequest(BaseModel):
    year: int = Field(
        1925,
        ge=1890,
        description="Year of the game, must be an integer starting from 1890.",
    )
    country: Literal["US", "PL", "ES"] = Field(
        ...,
        description="Country of the character's origin. Available options: 'US', 'PL', 'ES'.",
    )
    ...

tool_for_creating_character = FunctionTool.from_defaults(
    make_character,
    fn_schema=CreateCharacterRequest,
    description="Create a character.",
)

Writing a Pydantic model for the input schema also gives me a chance to reword some parameter descriptions, which helps the LLM understand the tool better. I can then get rid of the original docstring by overriding the description= in FunctionTool.from_defaults with a succinct one-liner. This also means our make_character function no longer needs its @wraps decorator. At this point, our tool looks like this to our agent:

Defining our own Python function

There are always going to be times when you have to build a tool from ground up. Rolling skill checks is a good example. The degree of success (success, failure, fumble, etc.) is determined by the rolled value, the skill value, and the difficulty of the situation. The formula can be encoded as huge chain of if-else statements:

def __map_dice_outcome_to_degree_of_success(
    difficulty: Difficulty, result: int, skill_value: int
) -> DegreesOfSuccess:
    if result == 100:
        return DegreesOfSuccess.FUMBLE
    if result == 1:
        return DegreesOfSuccess.CRITICAL_SUCCESS
    result_ignoring_difficulty = DegreesOfSuccess.FAIL
    if result <= skill_value // 5:
        result_ignoring_difficulty = DegreesOfSuccess.EXTREME_SUCCESS
    elif result <= skill_value // 2:
        result_ignoring_difficulty = DegreesOfSuccess.HARD_SUCCESS
    elif result <= skill_value:
        result_ignoring_difficulty = DegreesOfSuccess.SUCCESS
    # Now, we consider the difficulty.
    if difficulty == Difficulty.REGULAR:
        return result_ignoring_difficulty
    elif difficulty == Difficulty.DIFFICULT:
        if result_ignoring_difficulty >= DegreesOfSuccess.HARD_SUCCESS:
            return result_ignoring_difficulty
        # else, fall through to return a FAIL.
    elif difficulty == Difficulty.EXTREME:
        if result_ignoring_difficulty == DegreesOfSuccess.EXTREME_SUCCESS:
            return result_ignoring_difficulty
        # else, fall through to return a FAIL.
    return DegreesOfSuccess.FAIL

(Enum types Difficulty and DegreesOfSuccess are omitted. Remember to declare them as IntEnum, so that they can be compared with ">" and "<".)

The skill check procedure itself can be implemented in three lines:

def roll_a_skill(skill_value: int, difficulty: Difficulty = Difficulty.REGULAR) -> str:
    dice_outcome = random.randint(1, 100)
    return __map_dice_outcome_to_degree_of_success(difficulty, dice_outcome, skill_value)

To make it a tool, document it well:

def roll_a_skill(
    skill_value: int = Field(description="skill value", ge=0, le=100),
    difficulty: Difficulty = Field(description="difficulty level", default=Difficulty.REGULAR),
) -> str:
    """Roll a skill check and check the result."""
    dice_outcome = random.randint(1, 100)
    result = __map_dice_outcome_to_degree_of_success(difficulty, dice_outcome, skill_value)
    return f"You rolled a {dice_outcome}. That's a {result.name.lower().replace('_', ' ')}!"

Then we can simply wrap this function with FunctionTool.from_defaults. Notice that:

We didn’t create a standalone schema class for our tool. Instead, we annotated each parameter with a Pydantic Field. It threw me off a bit when I initially saw the practice of assigning Field objects to parameters that are clearly type-hinted otherwise, but it's a neat trick to keep the schema definition close to the function signature. This is a more concise way to define the schema, especially when the schema is simple.

We returned a natural-language string. The LLM is a language model, after all; it understands English better than it understands cold, hard JSON. When the output is not structured, always prefer natural language to code. How do you know? Here’s a rule of thumb: Tabular data or nested objects are structured data, whereas plain descriptions of facts can be considered unstructured, especially if they are short and/or has a natural order (like time of occurrence or logical chain). Our dice-rolling result is both short and logically ordered (we see the numerical outcomes first and then identify degrees of success, not the other way around), so it’s unstructured.

Photo by Shane Scarbrough on Unsplash

Creating a tool powered by LLM, for LLM

What can be more natural-language than a tool that relies on imagination?

In tabletop role-playing games, players often seek advice from the host. Inquiries may include:

• What are some skills to use / spells to cast in this situation?
• If I do this / say this, what would happen?
• What would be the best & the worst outcomes if I roll dices for this skill?

Before LLMs were popular, I couldn’t think of any better way to programmatically answer these questions than to encode every possible variable into a struct describing current situation and then look up from a massive database. But now, we can exploit LLM’s latent knowledge about how stories usually unfold. It’s literally a game changer.

Let’s make a tool that handles questions like “what can I do in this situation”. I want the AI Keeper to be able to suggest a few options and describe the potential outcomes of each choice. For example, if my Investigator has discovered a mysterious, ancient artifact in a hidden chamber when I asked this question, I want the chatbot to say something like this:

Archaeology

- Critical Success: You identify the artifact as a powerful relic from a lost civilization and uncover its true purpose. This knowledge provides a significant advantage in future encounters, as the artifact can be used to counter certain supernatural threats.
- Ordinary Success: You recognize the artifact as something ancient and possibly valuable, though its exact origin remains unknown. The group is cautious but unsure of its full potential.
- Failure: You misinterpret the symbols, believing the artifact to be a harmless trinket. This leads to a false sense of security, potentially causing problems when the artifact’s true nature is revealed.
- Fumble: Your examination triggers a hidden mechanism in the artifact, unleashing a dangerous curse or summoning a malevolent entity.

Occult

- Extreme Success: You decipher the symbols and realizes they are part of a ritual. You also understand how to safely control or use the artifact to protect the group from supernatural forces.
- Hard Success: You recognize the artifact as tied to dark rituals and understand the risks involved. The group decides to handle it with extreme caution.
- Failure: You sense something strange about the artifact but cannot determine its purpose. This uncertainty causes unease among the group.
- Fumble: You mistake the artifact for a harmless relic, and attempting to use it inadvertently invites dark forces or causes psychological harm.

Photo by Clint Bustrillos on Unsplash. Yeah, I know this isn’t CoC.

Unless you are using a model fine-tuned on Cthulhu Mythos, your AI keeper probably won’t answer things very Lovecraftian-ly. It may ruin the mood by suggesting escape routes like “call 911” and “leave the danger to the professionals”. To avoid that, we have to prime it (in the psychological sense) on some good examples. Each example should start with a description of situation, followed by a nested list of suggested skills and their possible outcomes, similar to the one above. Immediately after these examples is the template that the tool should fill in. Using the text completion API, the prompt should look like this:

Situation: The Investigator has discovered a mysterious, ancient artifact in a hidden chamber.
Suggested skills: [everything above]

Situation: The Investigator is trapped in a dark cave with no apparent way out.
Suggested skills: [some other suggestions]

Situation: {situation}
Suggested skills:

Here, {situation} is a placeholder for the AI Keeper to fill in. The prompt ends with "Suggested skills:", which signals the LLM to mimic the examples above. Now, if you use this prompt as-is, your chatbot may overfit to the examples, only suggesting skills seen in them. To avoid so, we can prepend a list of all possible skills in CoC to the prompt. This is like giving a crash course to the LLM before putting it to work. Putting it all together, my spin of the prompt ended up like this.

At this point, our prompt is going to be several thousands of words long. That’s awkward to manager as a string literal in Python. Let’s store it in a separate file and read it when constructing the tool.

class ToolForSuggestingChoices:
    def __init__(self, path_to_prompts_file: Path = Path("prompts/choices_prompt.md")):
        self.__prompt = path_to_prompts_file.read_text()
    def suggest_choices(
        self, situation: str = Field(description="a brief description of the situation")
    ) -> str:
        """
        If the user wants to know what skills their character can use in a particular situation (and what the possible consequences might be), you can use this tool.
        Note: This tool can only be used when the game is in progress. This is not a tool for meta-tasks like character creation.
        """
        prompt = self.__prompt.format(situation=situation)
        return Settings.llm.complete(prompt)

FunctionTool.from_defaults(
    ToolForSuggestingChoices().suggest_choices,
)

Many models come in two flavors: “instruct” that is fine-tuned for chatting and “text” that is fine-tuned for text completion. In some tricky situations, the text completion endpoint will be disabled on chat models (and vice versa), so you would need both models to drive the AI Keeper. This isn’t a concern if you’re using some remote API, but if you are serving LLMs locally, it might be too costly to load both variants into memory. Since the chat model is indispensable, we need to figure out a way to use a chat model for text completion. This requires us re-writing our prompt into a fake dialogue, where the system prompt will be the introduction of all possible skills, and then something along the lines of:

You are a Keeper of a Call of Cthulhu game. The user is your player. The player will describe a situation, and you will suggest some skills they can use in that situation. For each skill, describe the possible outcomes of using that skill. The player will then decide which skill to use.

Then, for each example, you wrap the description of the situation as a “User Message” and the suggestions as an “AI Message”. Repeat this foe all examples in your original prompt. Your tool should take the current situation as string and send it to the chat interface, along with the fake dialog as chat history. Basically, we are “brainwashing” the same LLM to think it has a second persona that is solely responsible for suggesting skills. This way, we don’t need to load another model into RAM, potentially halving the memory usage.

Conclusion

In this post, we walked through four common means of building agentic tools for AI chatbots. To recap, they are:

• importing a pre-packaged tool specific to your framework of choice (LlamaIndex in my case),
• wrapping an arbitrary Python library into a tool,
• declaring any Python function as a tool, and, as a special case of this,
• creating a tool powered by LLM’s text completion capabilities.

Particularly, we emphasized on what kind of functions should be implemented with a LLM and what should stick with the traditional programming paradigm. To summarize, tasks that have well-defined procedure to follow or require strict adherence to certain rules, such as mathematical computations, should stay in the coding realm, whereas those that rely on creativity or are awkward to script can be gracefully — albeit less reliably — delegated to LLMs. If you are just starting out with AI agents, tools described in this post can serve as great examples.

Up till now, we have been making the chatbot capable of holding a meaningful conversation. In the next installation of the series, let’s switch topic and talk about the cosmetics. Can we show some animation of dices rolling on a wooden table when we invoke the dice-rolling tool? Can we ask Stable Diffusion to paint an illustration of the scene while our LLM narrates the story? Those questions will be explored in our next post. Stay tuned!
